Rung 2: the agent gets its own box

What you get #

The agent runs on its own box, so the box stays up while infra is maintained, rebooted or down, and its builds no longer share infra’s memory. While infra is down, whatever the agent reaches through infra stops: model calls through the gateway, the forge, the password manager and every other service on infra.

• The box configures itself from the forge, and a deploy that breaks it rolls back with no one at the box.
• Secrets are encrypted in the repository to three keys: the box’s own, the laptop’s, and an offline master key kept only in the password manager for emergencies (break-glass).
• The agent account is unprivileged, allowed to start only the box’s own named jobs.
• A watcher notifies you when something on the site stops answering.
• Infra and this box are both configured as subnet routers on your tailnet (your Tailscale network): each relays traffic from your devices away from home to the home network. On the bench this box carried the route; infra’s stayed a standby, configured but not yet tested, so remote access with this box down is not proven.
• Backups of the agent’s work every two hours, to infra’s append-only backup server.

Buy. One small always-on x86 box: an N100-class mini PC for agents only, or an eight-core mini PC with two NVMe slots if it is also the development box (sized under Decisions and options).

What still fails. Names, time and the main monitoring still run on infra; with infra down, the agent box stays up and its watcher still reports, but the house loses DNS and the agent loses its models. Rung 3 moves names, time and notifications off infra; model calls through infra’s gateway still stop.

Stop here if your agent is the main thing you run, and a few minutes of DNS outage when infra restarts is fine.

Decisions and options #

A small x86 box with a fast drive, sized for what the agent will do.

• For agents only. An N100-class mini PC with 12 to 16 GB and a 2.5 GbE port. Agents that call models through the gateway need little memory of their own.
• For agents and development. 8 cores, 32 to 64 GB and two NVMe slots, so builds, test VMs and several worktrees fit beside the agents.

Ours is the first kind: a Chuwi LarkBox X (Intel N100, 12 GB soldered, 11.7 GiB usable), on its 2.5 GbE port. Ours has 12 GB, the low end of the range above; for a box that only runs agents that was enough. Over 4.2 days of monitoring (20260924 to 20260928), available memory never fell below 8.1 GiB, swap peaked at 24 MiB, memory pressure at 0.4%, and nothing was killed for lack of memory.

• Two boxes of the same model shipped with different storage. One had a SATA SSD, the other NVMe. Check which yours has before planning the disk layout.
• A firmware fault on our unit. Saving any firmware setting left it unable to boot until a CMOS battery reset, which also erased the settings. So it cannot keep “power on after AC loss”, and it stays off after a power cut. While powered it was stable through two hours of full CPU and memory stress, three warm restarts, and a 16 GiB write and read-back test. We run it on the UPS and never cut its power. If your box shows this, ask the maker for a batch-specific firmware; none is published. Would change it: a box that keeps its firmware settings.

Installed over ssh, with no hands after the first boot.

• The first NixOS install uses the stock installer, which logs in at its console and already runs ssh. At that console, put the agent’s public key in ~/.ssh/authorized_keys: mkdir -p .ssh; chmod 700 .ssh, echo '<public key>' > .ssh/authorized_keys, chmod 600 .ssh/authorized_keys. These are the three lines typed for the rung 1 VM on 20260923; the lines typed on the rung 2 box itself were not recorded. Then the agent installs over ssh from the flake.
• After that, the agent builds a keyed installer image, writes it to the box’s own USB stick (found by serial), sets a one-time boot to it, and reinstalls with no one at the box. The one-time boot worked on our box, so we never needed the fallback of kexec (starting the installer’s kernel from the running system).
• Check the firmware’s boot entries after an install. Ours still pointed at the old, wiped boot partition, so the next reboot would have started the installer again. Add an entry for the new partition and put it first.

The disk layout keeps /work separate. 1 GiB boot, 100 GiB root, the rest as a partition for /work, declared in the flake with disko (NixOS’s declarative disk layout) but without a filesystem, so no install or reinstall can format it. Its XFS filesystem is made once by hand. A reinstall formats boot and root and leaves /work alone.

• Pin the work volume’s UUID, and keep the agent’s logins, keys and state on it through bind mounts, so a rebuild needs no new logins.
• On a box with two NVMe slots, the second drive is the work volume, mounted before the first repository is cloned. On a one-drive box, as ours is, a partition does the job.

The box resolves names without infra. It carries the site’s few addresses in its own hosts file, from the repository, so it never depends on the thing it is watching.

Pull-deploy from the forge. The box pulls the deploy branch every 15 minutes with a read-only deploy key and a pinned forge host key. Promotion to deploy is by merge only, after a required build check has built every host. Would change it: push-based deploys from a workstation are fine for one person with one box. Use pull-deploy once agents change the configuration, so every change reaches the box through a merge and the build check.

Secret handling with sops-nix and three age recipients. sops-nix decrypts the repository’s secrets on the box at activation; age is the encryption, and each recipient is a key that can decrypt. The box decrypts with its own ssh host key, so keep a copy of that key off the box. The offline master key can decrypt everything too, which is what lets you re-encrypt the secrets to a new set of keys (secrets-rekey.sh ).

A bad deploy rolls back with no one at the box. A box that loses its network after a deploy cannot fetch the fix. NixOS keeps older generations in the boot menu, but choosing one needs someone at the console. The three pieces below remove that step. On 20260928 we deployed a generation with no network on purpose, and the box was back on the last good generation 22.5 min later, after 3 tries of about 7 min 20 s each (data ).

• Boot counting (systemd-boot’s automatic boot assessment). A new generation gets 3 tries and is marked good only when a check after boot proves the network, ssh, the forge and /work. A generation that never passes gives way to the last good one by itself. The loader counts tries only against its preferred entry, and NixOS writes only default. So write preferred for the new generation, and point default at the last generation that booted and was marked good (boot-assessment.nix does both).
• A fixed rescue entry. A small system that runs from memory, installed on the boot partition independently of every deploy, with a known network address and ssh. It boots to ssh in 27 s (rescue-entry.nix ; the tests are in rescue-boot.md ).
• The hardware watchdog, with panics on boot failure and no emergency shell, so a hung boot becomes a reset and counts as a try.

The watcher is one scheduled script. It checks DNS, the backups and the web front door, and sends one line when any of them fails. Beyond the agent, the box carries only the watcher and its Tailscale subnet router.

• It probes more than the front page. It also asks Unraid’s own web page on port 80, which answers even when the array is stopped, so its message tells “infra is up but its services are not” apart from “infra is gone”. Every network check has a timeout, and a run can never outlive its cycle.

Costs and measurements #

• The box: about $240 for an N100 box (ours sells for $234.88), or about $960 for an eight-core Ryzen mini PC with 64 GB and a second NVMe: a Minisforum UM890 Pro (Ryzen 9 8945HS, 64 GB, 1 TB) was about $800 and a second 1 TB NVMe $150 to $320, checked 20260928 (costs ). Ours was spare hardware.
• Power: its sibling of the same model drew 5.9 W idle on a plug meter. Ours has no meter of its own; by subtraction from the UPS input it draws at most about 16 W at rest (data ).
• A warm restart takes 27 to 33 seconds back to ssh (data ).
• A rebuild from the forge, keeping /work, takes about 4 minutes from restart to answering. On 20260927 it took 12 min 13 s, 8 of them spent waiting with the box on the wrong network port, and the work volume came through untouched (data ).

Runbooks #

Not yet written as numbered steps for your site. The bench’s own runbooks exist for each part, with the bench’s names and addresses; read them as worked examples.

1. First install over ssh: rung2-agent-install.md (the plan as written before the install; it covers the keyed installer and the one-time boot).
2. The no-hands reinstall that keeps /work: rebuild-agent-box.md .
3. Pull-deploy, and promoting a change through the build check: promote.md .
4. Moving the agent (its tools, logins, keys and work) from the VM to the box: move-builder-to-agent.md .
5. Testing the rollback and the rescue entry: rescue-boot.md .

Configuration #

Not yet templated. The bench’s flake is in as-built/nixos/ : the agent host and its disk layout (hosts/agent/default.nix, hosts/agent/disko.nix), and the pull-deploy, watcher, agent-tools, boot-assessment and rescue-entry modules in modules/. The sops configuration is not in the repository; the encrypted secret files were left out at export.

Before it: Rung 1: the infrastructure box . After it: Rung 3: the core box . The whole ladder: the Seed .
